Horizontal Latch Clamps

  • Range:Toggle Clamps
  • Category:Manual Toggle Clamps
  • Group:Toggle Latches/Latch Clamps
  • Style:Horizontal Latch Clamps
Search on complete or part product code

Horizontal Latch Clamps

Select product to view cad download options
Horizontal Latch Clamps
Horizontal Latch Clamps
DrawingsPDF
Part No.
LU200H 135 42 23 5.2 13 19 200daN 0.05Kg CAD / BUY
LU400H 185 63 32 6.5 19 25 400daN 0.25Kg CAD / BUY
LU700H 250 84 40 8.5 32 36 700daN 0.70Kg CAD / BUY
LU2000H 320 115 65 10.3 N/A 50 2000daN 1.40Kg CAD / BUY
LU4000H 395 132 78 12.4 N/A 56 4000daN 2.60Kg CAD / BUY
LU323 110 30 20 4.3 15.9 19.1 170daN 0.16Kg CAD / BUY
LU331 170 44.4 25.4 6.3 19 31.8 320daN 0.23Kg CAD / BUY
LU341 243 75 38.1 8.5 41.3 38.1 900daN 0.68Kg CAD / BUY
LU375 280 104 57.2 10.3 57.2 57.2 1800daN 1.80Kg CAD / BUY
